Camera | |
Image Sensor: | 1/2.8" Progressive Scan CMOS |
Effective Pixels: | 1920(H)x1080(V) |
Signal System: | PAL/NTSC |
Minimum Illumination: | Color: 0.05 Lux @(F1.5, AGC ON) |
B/W: 0.01 Lux @(F1.5, AGC ON) | |
0 Lux with IR | |
AGC: | Auto/Manual |
BLC: | ON/OFF |
HLC: | Support |
Smart defog: | Support |
WDR: | 120dB |
Shutter Time: | 50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s |
Day& Night: | ICR |
Digital Zoom: | 16X |
Privacy Mask: | 24 programmable privacy masks |
Auto Focus: | Auto / Semi-automatic / Manual |
Lens | |
Focal Length: | 6.6 mm to 330 mm, 50× Optical |
Zoom Speed: | Approx. 4.5 s (optical lens, wide-tele) |
Field of View: | Horizontal field of view: 41.3° to 1.1° (wide-tele) |
Vertical field of view: 23.6° to 0.6° (wide-tele) | |
Diagonal field of view: 47.4° to 1.3° (wide-tele) | |
Minimum Working Distance: | 10-1500mm(Wide-Tele) |
Aperture Range: | F1.8~F5.5 |
Pan & Tilt | |
Pan Range: | 360°endless |
Pan Speed: | Configurable, from 0.1°/s to 210°/s, Preset Speed: 280°/s |
Tilt Range: | -20°~90°(Auto Flip) |
Tilt Speed: | Configurable, from 0.1°/s to 150°/s, Preset Speed: 250°/s |
Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples |
Number of Preset: | 300 |
Patrol: | 8 patrols, up to 32 presets per patrol |
Pattern: | 4 patterns, with the recording time not less than 10 minutes per pattern |
Power-off Memory: | Support |
Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
PTZ Position Display: | ON/OFF |
Smart-tracking: | Manual/ Panorama/ Intrusion trigger/ Line crossing trigger / Region entrance trigger / Region exiting trigger |
Wiper: | Optional |
Infrared | |
Laser Distance: | 800 m |
IR irradiation angle: | Adjustable by zoom |
Alarm | |
Alarm Input: | 7 Inputs |
Alarm Output: | 2 |
Alarm Linkage: | Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel |
Network | |
Ethernet: | 10Base -T, /100Base-TX, RJ45 Connector |
Main Stream: | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720), |
50fps (1920 × 1080, 1280 × 960, 1280 × 720); | |
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720), | |
60fps (1920 × 1080, 1280 × 960, 1280 × 720) | |
Sub Stream: | 50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240) |
Third Stream: | 50Hz: 25fps(704×576, 640×480, 352×288); |
60Hz: 30fps(704×480, 640×480, 352×240) | |
Video Compression: | Main Stream: H.265+/H.265/H.264+/H.264 |
Sub-Stream: H.265/H.264/MJPEG | |
Third Stream: H.265/H.264/MJPEG | |
ROI encoding: | Eight fixed region for each stream |
Audio Compression: | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
Audio Mode: | OFF/Audio input/Audio output |
Protocols: | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
Simultaneous Live View: | Up to 20 channels |
Three-Stream: | Support |
Storage: | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
Security Measures: | User authentication (ID and PW), |
Host authentication (MAC address) | |
IP address filtering | |
Client GUI | |
Camera Control: | Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
Date & Time Display: | Time: Week: Date, 6 formats on the Client |
Client: | Support iVMS-4200 |
Web Browser: | IE 7+, Chrome 18 - 42, Firefox 5.0 +, Safari 5.02 + |
General | |
RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
Power Supply: | 24 VAC & Hi-PoE |
Power Consumption: | 24 VAC (Max. 60 W, including max. 18 W for IR and max. 12 W for heater) |
Hi-PoE (Max. 50 W, including max. 18 W for IR and max. 12 W for heater) | |
Working Temperature/Humidity: | -40°C to 70°C (-40°F to 158°F) |
Protection Level: | IP67 Standard, IK10 (only supported by camera without wiper), TVS 6,000V Lightning Protection, Surge Protection and Voltage Transient Protection |
Giá sản phẩm trên Tiki đã bao gồm thuế theo luật hiện hành. Bên cạnh đó, tuỳ vào loại sản phẩm, hình thức và địa chỉ giao hàng mà có thể phát sinh thêm chi phí khác như phí vận chuyển, phụ phí hàng cồng kềnh, thuế nhập khẩu (đối với đơn hàng giao từ nước ngoài có giá trị trên 1 triệu đồng).....
Thương hiệu | Hikvision |
---|---|
Kích thước | Φ266.6 x 410 mm |
Model | DS-2DF8250I8X-AEL(W) |
Trọng lượng | 8kg |
SKU | 8589016399084 |
